GHF280F Plastic sealed multifunctional powder packaging machine
The multifunctional plastic packaging machine is an advanced technology independently developed by our company. It is a high-quality and high-performance fully automatic packaging machine. It can be packaged in three forms (triangle bag, three side seal, back seal). Click on the interface "Triangle bag three side seal back seal" to change the packaging form, and switch with one click is simple and convenient. This machine has the functions of automatic bag making, measuring, filling, sealing, cutting, counting, etc. It adopts advanced microcomputer controller and servo motor to control bag length and trademark positioning. The machine has stable performance, easy adjustment, accurate detection, and intelligent control with minimal stroke error. Corresponding feeding mechanisms can be prepared according to different materials. The whole machine is easy to operate and perfect, making it the preferred equipment for improving production efficiency, reducing labor intensity, and enhancing packaging quality in the food packaging industry.
Description
The multifunctional plastic packaging machine is an advanced technology independently developed by our company. It is a high-quality and high-performance fully automatic packaging machine. It can be packaged in three forms (triangle bag, three side seal, back seal). Click on the interface "Triangle bag three side seal back seal" to change the packaging form, and switch with one click is simple and convenient. This machine has the functions of automatic bag making, measuring, filling, sealing, cutting, counting, etc. It adopts advanced microcomputer controller and servo motor to control bag length and trademark positioning. The machine has stable performance, easy adjustment, accurate detection, and intelligent control with minimal stroke error. Corresponding feeding mechanisms can be prepared according to different materials. The whole machine is easy to operate and perfect, making it the preferred equipment for improving production efficiency, reducing labor intensity, and enhancing packaging quality in the food packaging industry.
This machine is a multifunctional packaging equipment that can seal and package particles, powders, and liquids in an automated and precise manner. It is suitable for packaging in industries such as food, medicine, chemical, and cosmetics.
This machine can be equipped with assembly lines, with stable performance and a wide range of applications.
Three sides
| Total Power | AC220V，50-60Hz ，1.6kW |
| air consumption | HS sealing 0.1NL/cycle |
| compressed air | Min 0.5MPa |
| Thin film materials | Packaging film with or without cursor, heat sealable |
| Outer diameter of roll film | Max：320mm |
| Inner diameter of roll film paper core | 76mm |
| Packing Speed | 30-80 bags / min |
| Packaging film size | Max film width: 180mm (triangular bag), 220mm (three side seal) |
| Machine appearance dimensions | L753mm×W1205mm×H1957mm(Customizable according to customer requirements) |
| machine weight | ~220kg |
| environmental conditions | Relative humidity of 30% to 90%; The ambient temperature ranges from 0 ℃ to 40 ℃ |
| bag width | 60-110mm (three side seal) |
| bag length | 80-140mm |
