160J horizontal sauce bag packaging machine
This horizontal pre-made pouch sauce packaging machine offers precise 20–500g dosing, handles 80–240mm (L) × 60–170mm (W) prefab bags, and operates at 20–35 bags/min. It runs on AC220V/50–60Hz/2kW, requires ≥0.6Mpa gas, and has dimensions of 1424×980×1343mm with a 450kg weight, ideal for reliable sauce packaging in food processing.
Description
This horizontal pre-made pouch sauce packaging machine is engineered for precise and efficient packaging of sauce products within a measuring range of 20–500g. It accommodates prefabricated bags with dimensions of 80–240mm (L) × 60–170mm (W), delivering a packaging speed of 20–35 bags per minute.
With a compact footprint of 1424 × 980 × 1343mm and a net weight of 450kg, the machine operates on a power supply of AC220V / 50–60Hz / 2kW and requires a gas source pressure of ≥0.6Mpa for optimal performance. Its robust construction and reliable operation make it an ideal solution for food processing businesses seeking consistent, high-quality sauce packaging.
Equipment Technical Specifications Detailed performance parameters of the packaging equipment.
| Measuring Scope | 20-500g |
| Prefab bag Length（L） | 80-240mm |
| Prefab bag Width（W） | 60-170mm |
| Packing Speed | 20-35bags/min |
| Dimension（L*W*H） | 1424 * 980 * 1343mm |
| Weight | 450kg |
| Power | AC220V/50-60Hz/2kw |
| Gas source | ≥0.6Mpa |
