LK-QK Particle packaging machine

1.It can automatically complete bag making, metering, feeding, sealing, slitting and counting, and can be equipped with functions such as batch number printing according to customer requirements.

2. 7-inch touch screen with Chinese and English operation, simple and intuitive to operate. Adopting a PLC control system for more stable operation. Stepper motor controls bag length with convenient and stable bag length setting. It features stable performance, easy adjustment and accurate detection. The intelligent temperature controller adopts PID automatic temperature adjustment, keeping the temperature error within 1°C.

3.Packaging materials: Polypropylene / polyethylene, aluminum foil /polyethylene, polyester / aluminized / polyethylene, nylon / reinforced polyethylene, paper / polyethylene, etc.

Description

For:

Suitable for the quantitative packaging of various grains, wolfberries, snacks and nuts, hardware accessories and other products in the food and industrial industries.

Technical parameters:

ModelLK-QK
Bag SizeLength: 30-210mm, Width: 45-300mm
Sealing TypeThree-side seal / Back seal (Convertible on one machine)
Blanking MethodRotary table blanking
Packing Speed30-80 bags/min (Depending on material)
Measuring Scope3-100 ml (Depending on material)
Total Power220V/50Hz/1.4kW
Weight350 kg
Overall Dimension1050 × 800 × 1580 mm
